CD4047 Astable/Monostable Multivibrator IC-14 Pins – 1 Pcs

Description

CD4047 Astable/Monostable Multivibrator IC-14 Pins – 1 Pcs

The CD4047 is a versatile IC capable of operating as both an astable and monostable multivibrator. It features gatable astable operation and supports positive or negative edge-triggered monostable modes with retriggering and external counting options. This IC is ideal for generating precise time delays, oscillation, and pulse-width modulation. An external capacitor and resistor are required for setting the frequency and timing in both astable and monostable modes. The oscillator output offers a period that is half of the Q output in astable mode, providing reliable frequency generation for various applications.

Key Features:

✔ Dual Operating Modes: Supports both astable (free-running) and monostable (one-shot) modes.
✔ 50% Duty Cycle: Ensures balanced output in astable mode.
✔ Oscillator Output: Provides a frequency that is half of the Q output.
✔ Edge Triggering: Supports both positive and negative edge triggering.
✔ Pulse Width Expansion: Retriggerable option allows pulse width expansion in monostable mode.
✔ Power-On Reset: Built-in internal power-on reset circuit for stable startup.
✔ Frequency Stability: Offers good frequency stability in astable mode.

Product Specifications:

⚡ Supply Voltage Range: 3V to 15V
⚡ Operating Temperature Range: -55°C to +125°C
⚡ Package Type: DIP-14
📏 Applications: Timers, pulse generators, oscillators, frequency dividers.

Ideal for:

🔋 Oscillator Circuits: Generate stable square waves for clocks and signal generators.
📟 Timers: Create precise time delays for control systems.
🛠️ Pulse Width Modulation (PWM): Used in motor speed controls and power regulation.
📡 Frequency Dividers: Useful in communication systems and digital counters.

Package Includes:

📦 1 x CD4047 Astable/Monostable Multivibrator IC-14 Pins
