Description

The SIM800L GSM/GPRS Module is a compact and powerful GSM modem ideal for IoT, embedded, and communication-based projects. It offers functionality similar to a mobile phone—allowing you to send SMS, make and receive calls, and connect to the internet using GPRS with TCP/IP support. With quad-band GSM capability, it works reliably across most regions worldwide. Its small size and wire antenna make it perfect for space-constrained applications.

---

KEY FEATURES

• Quad-Band Support: Works on 850 / 900 / 1800 / 1900 MHz GSM networks
• Full GSM Functions: Supports SMS, voice calls, and GPRS data
• Internet Connectivity: TCP/IP stack for IoT and remote communication
• AT Command Control: Compatible with standard and SIMCOM-enhanced AT commands
• Low Power Consumption: Only 1mA current in sleep mode
• Compact Design: Ideal for embedded and narrow-space applications

---

SPECIFICATIONS

• Module Type: GSM/GPRS Communication Module
• Model: SIM800L
• SIM Type: Micro SIM
• Network Bands: 850 / 900 / 1800 / 1900 MHz
• GPRS Class: Multi-slot Class 12 (Max 85.6 kbps DL/UL)
• Mobile Station Class: Class B
• Supply Voltage: 3.4V – 4.4V
• Logic Level Support: 3.0V – 5.0V
• Sleep Current: ~1mA
• Additional Support: A-GPS, Real-Time Clock (RTC)

---

BENEFITS

• 📡 Global Compatibility: Works on GSM networks worldwide
• 🔌 Perfect for IoT: Ideal for remote monitoring and automation projects
• 🔋 Energy Efficient: Low power usage extends battery life
• 🧠 Easy Integration: Simple AT command interface
• 🛠 Compact & Flexible: Fits easily into small DIY and industrial designs

---

📦 PACKAGE INCLUDES

• SIM800L GSM/GPRS Module: 1 Unit
• Antenna: 1 Wire Antenna
