Common Anode 4 Leg Milky Lens RGB LED-5mm – 5 Pcs Pack

Description

Common Anode 4 Leg Milky Lens RGB LED-5mm – 5 Pcs Pack

The 5mm Round Milky RGB Common Anode LED is a versatile and widely used component in various electronic circuits and devices. With its four terminals, it offers individual control of red, green, and blue light, making it ideal for creating a range of colors.

Key Features:

• Forward Voltage: 3.0V – 3.4V
  • Compatible with standard low-voltage power supplies.
  • Ensures stable and efficient operation.
• Pin Configuration: 4 Pins
  • Common Anode (+): Long leg for easy identification.
  • Red (-)
  • Green (-)
  • Blue (-)
• Lens Color: Milky White
  • Provides a diffused light output.
  • Enhances color blending and visibility.
• Size: 5mm Diameter
  • Standard size for through-hole LEDs.
  • Easy integration into various projects.
• Mount Type: Through Hole
  • Secure and durable mounting on PCBs.
• Low Power Consumption:
  • Energy-efficient.
  • Suitable for battery-operated devices.
• Wide Viewing Angle:
  • Ensures visibility from different angles.

Applications:

1. Industrial Applications:
   • Used in machinery and equipment for status indicators and alerts.
2. Portable Flashlights:
   • Provides versatile lighting solutions with RGB color options.
3. Decorative Lighting:
   • Ideal for creating colorful displays in home decor, events, and festive decorations.
4. LCD Backlight:
   • Used in displays for providing backlighting and enhancing visual appeal.
5. DIY Projects and Repairs:
   • Convenient for hobbyists and technicians for creating custom lighting solutions and repairing electrical appliances.

Specifications:

• Product: RGB LED Common Anode 4-Pin
• Input Voltage: 3.0V – 3.4V
• Type: Common Anode
• Diameter: 5mm
• Lens Color: Milky White
• Number of Pins: 4
• Mount Type: Through Hole
• Pin Type: Long Leg (LL) for the common anode

Usage Tips:

1. Correct Polarity:
   • Ensure the common anode (long leg) is connected to the positive voltage.
   • Connect the other three legs to the respective control signals for red, green, and blue.
2. Current Limiting Resistors:
   • Use appropriate resistors to limit current and prevent damage to the LED.
   • Calculate the resistor values based on your supply voltage and desired current.
3. Heat Management:
   • Ensure proper ventilation or heat sinks if used in high-temperature environments.
