3 Pin Blue Color SPDT 3 leg Toggle Switch

Description

SPDT On-On Toggle Switch (3 Pins)

The SPDT (Single Pole Double Throw) On-On Toggle Switch is a versatile and durable switch designed for a wide range of electrical applications. With three terminals, this switch can connect a common terminal (COM) to one of the two output terminals (A or B), providing two output options but only one active at a time. This functionality is especially useful in three-way circuits to control an electrical appliance from two different locations. The switch is robust and suitable for high-power applications, offering a reliable solution for your electrical switching needs.

Features & Specifications:

• 🔌 Type: SPDT (Single Pole Double Throw) Toggle Switch
• 🔀 Configuration: On-On (One of Two Outputs Active at a Time)
• 📌 Terminals: 3 Pins (1 Input, 2 Outputs)
• 🏗️ Material: External Parts Made of Metal for Durability
• ⚡ Power Rating: 15A at 250VAC

Mechanical Specifications:

• 📏 Dimensions: 29mm x 16mm x 56mm
• 🔧 Dielectric Strength: 1000V RMS (Minimum)
• 🛡️ Insulation Resistance: 100 MΩ (Minimum)

Electrical Specifications:

• ⚡ Power Rating: 15A at 250VAC

Applications:

• 🔌 Three-Way Circuits: Ideal for Controlling Electrical Appliances from Two Different Locations
• ⚙️ High-Power Switching: Suitable for Applications Requiring Reliable and Robust Switching
• 🛠️ DIY and Prototyping: Useful for Various Electronic Projects and Prototypes

Benefits:

• ✅ Reliable and Robust Performance
• 🔒 Enhanced Control in Multi-Point Switching Systems
• ⚡ High Power Handling Capacity

Package Includes:

• 📦 1x SPDT On-On Toggle Switch (3 Pins)
• 🎁 Cap: Product Comes With or Without a Cap, Sent Randomly**
