1S 2A BMS For 3.7v-18650 Lithium Battery Protection – 1 Pcs
₹25.00 Original price was: ₹25.00.₹18.00Current price is: ₹18.00.
- High-accuracy voltage detection circuit
- Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit)
- Two MOS transistor can control the battery charge and discharge
- low standby current consumption
22 in stock
Add to Wishlist
Add to Wishlist
Description
1S 2A BMS For 3.7v-18650 Lithium Battery Protection – 1 Pcs
1S 2A Li-ion Lithium Battery 3.7V – 4.2V 18650 Charger Protection Board Module is a small PCB mounted Li-ion Lithium Battery charger protection module. This small and smart battery charger protection module comes with various features like Short circuit protection, Overcharge protection, Over-discharge protection, Overcurrent protection. It is very easy to install and convenient to use in all your DIY portable projects.
Features:
- High-accuracy voltage detection circuit
- Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit)
- Two MOS transistor can control the battery charge and discharge
- low standby current consumption
PACKAGE INCLUDE:
1X 1S 2A BMS For 3.7v-18650 Lithium Battery Protection
Additional information
| Overcharge voltage | 4.2-4.3v |
|---|---|
| Over-discharge voltage | 2.5-3.0v |
| Maximal continuous charging/discharge current | 10A |
| Color | Blue |
| Size | 41 x 16 x 3.5mm. |
| Resistance | Less than 300mΩ |
